FOOD SERVICE STATIONARY

Commercial and Industrial ProductsMobile Refuse Products

Cart Compatibility

Drums

Mounting Height

N/A

Application Types

Compactor

C/I Food Services Series Lift Units

The Food Services series from Bayne Premium Lift Systems are the perfect lifting solution for supermarkets, restaurants, cafeterias, bakeries, commercial kitchens, and more. These food service units make short order of waste disposal. Sized to fit typical food waste containers, our Food Services cart lifters, or cart tippers, are also equipped with a chute to prevent trash spillage, Food service units can be moveable or fixed, and include a fork pocket for easy transport. These lifters help to minimize the risk of back injury and enhance worker safety.

C/I Food Service Series Features

  • Compatible with typical food service type waste containers
  • 230/460 volt 3-phase AC, 110/220 volt 1-phase AC and 12 volt DC self-contained hydraulic power units available
  • Cycle times as low as 12 seconds
  • Welded cylinder with replaceable seals
  • Self-lubricating composite bearings at main pivot points
  • Powder coated finish for durability
  • 1-Year Limited Warranty
  • Cart Compatibility

    Food service type round/rectangular waste containers
  • Lift Capacity

    500 lbs. @ 2000 psi
  • Voltage (60 Hz)

    230/460 volt 3-phase AC 110/220 volt 1-phase AC 12 volt DC
  • Hydraulic Pressure

    2500 psi maximum
  • Hydraulic Flow

    1.8 gpm
  • Cycle Time

    12 seconds
  • Bearings

    Self-Lubricating Composite Material
  • Finish

    Safety Yellow Powder Coating

Request Product Info
