BTL 208 Slider Latch 1999-0212

BTL 208 Slider Latch Cart Lifter

The BTL 208 series is one of the newest and most advanced lines of refuse collection vehicle cart lifters from Bayne Premium Lift Systems. The patent-pending design of the BTL 208 series incorporates a sweeping action that automatically adjusts for uneven terrain, preventing operators from having to lift carts onto the lifter faceplate. This cart lifter, or cart tipper, was specifically designed for rear- load applications. It offers greater ground clearance and is thin enough to work in conjunction with commercial container latch kits. This enables one garbage truck to pick up both residential and commercial waste on the same route.

BLT 208 Series Features

• Powered by the patented Thinline^® rack-and-pinion rotary actuator for smooth operation
• Compatible with standard domestic style 2-bar roll-out carts
• Sweeping motion allows for an increased cart pick-up envelope
• Over 20″ of ground clearance
• Thinline® design works in conjunction with most commercial container latch kits
• Dumps cart higher and deeper inside the hopper opening to prevent spillage and increase route stops before cycling packer panel
• Powder-coated finish for durability
• 2-Year Limited Warranty
